Weatherproof SOS Telephone Stations

VoIP SIP PoE, 3G GSM, or Analogue, Line Powered

Floor Mounted Emergency Call Pillar

Model: AJR-TP03

  • Wireless 3G, Analogue or VoIP SIP
  • Choice of any Weatherproof Series Telephones
  • Solid & Robust Non-Corrosive Steel Structure
  • Vandal Proof Pillar &Telephones
  • Weather Protection Rated IP66-67
  • Simple Installation with Tamper Proof Fixings
  • Non-volatile Memory, Programmable for Speed-Dialling
  • Disabled Assistance - Hearing Induction Loop
  • Protected Against Extreme Weather Conditions
  • Remote programming SMS or DTMF (version dependant)
  • Choice of Customised Labelling and Colours
  • RoSH, CE & FCC Compliant - 24 Month Warranty


  • ----- Silk Printing and Permanent Vinyl Labels -----

    FREE Customised Permanent Adhesive Labels and LOW COST Factory Silk Printing.

    Simply tell us what you want and we will provide you with the best solution.

    customised printing or permanent logos onto telephones and call points

    An Ideal Secure Solution for Remote and High-Risk Areas

    The Pillar is made from galvanised and cold rolled steel and finished with durable high-gloss, multi-layer, corrosion-inhibitive powder paint. Offers full protection against vandalism and extreme weather conditions, whilst ensuring that the primary function of communications is maintained at all times.

    Telephone Type and Power Options

    Choose from 3G GSM, powered by rechargeable interchangeable 30-day batteries or by mains powered. Also available to analogue (line powered) or SIP VoIP powered by PoE

    Choice of Weatherproof Series Telephones - IP66 as Standard - IP67 available upon request

    Weatherproof Robust Series Telephones are designed for use in adverse temperatures ranging from -25 to +70 deg C. The loud ringer with quality clear audio is adjustable up to 95dB (VoIP / GSM) and 80DB (Analogue). Additional external ringers / repeaters and LED flashing beacons can be specified for use in extreme ambient noise zones. The weatherproof IP66 rating conforms to EN60529, guarantees optimum performance in uncompromising environments, even when the door is open. Full Duplex, High Quality Microphone and Audio, adjustable during installation or remotely by DTMF or Text Message (Version Dependent) to ensure optimum locational performance.

    Robust and Vandal Resistant

    Housed within sold cast aluminium casing, a unique external telephone compromising off a robust handset, steel armoured cable and anti-tamper fixings. The rugged telephone is ideal for placing within heavy Industrial Emergency locations.

    Floor Mounting

    Option to fit directly into the ground with four foundation or expansion bolts (not supplied). The frame is supplied with four bolt holes pre-drilled into the base bracket and concealed behind a steel base plate, provides extra protection against weathering and vandalism.

    Internal Relay's - controlled by Operators Telephone Keypad

    Up to 2 internal relays are available to the VoIP telephone as standard, however the Analogue Version can be customised to include 2 relays upon request. Remote users can enter PIN codes via telephone keypad for remote actions, such as, door / gate open, sound an alarm, switch on a camera / light etc.

    Disable Assistance Fitted Hearing Loop Technology

    Induction Loop Technology is fitted to the telephone handset as standard to assist hard of hearing users.

    Simple to Setup and Maintain

    Remote Programming by way of DTMF for Analogue Networks and powered by Analogue Line. The VoIP SIP version is powered by PoE, the 3G Wireless GSM Version is powered by 12V Mains Adaptor and setup remotely by SMS Text. Message Status Reporting also available to a dedicated mobile number (SMS), this is very simple to setup and manage.

    Choice of Colours

    Powder Coated RAL1023 yellow as standard, however, other RAL colours are available up-on request.

    FC - This mark indicates compliance with FCC Part 15 Subpart B Class B

    CE - This mark indicates compliance with the: Radio and Telecommunications Terminal Equipment Directive 2004/108/EC

    Analogue Version
    Power Supply Analogue Telephone Network
    Supply Voltage 24 VDC to 65 VDC
    Supply Current 20 mA DC to 100 mA DC
    Ringer Volume 80dB(A) at 1m. 110dB(A) at 1m with external horn speaker
    Dialing Method DTMF mode in accordance with ITU-T recommendation Q.23.
    SIP Version
    Power Supply PoE or 12V DC
    Power Consumption Idle:1.5W-Active:1.8W
    SIP Protocol SIP 2.0 (RFC3261)
    Support Codec G.711 A/U, G.722 8000/16000, G.723, G.729
    Communication Type Full Duplex
    Ringer volume 90~95dB(A) at 1m. 110dB(A) at 1m (external horn speaker)
    3G Version
    Power Supply 12V DC or Rechargeable Battery
    Power Consumption Idle:0.3W - Active: 1.5W
    Communication Type Full Duplex
    Ringer Volume 90~95dB(A) at a distance of 1m
    Program Method Remote Programming by SMS
    Frequency
    A version: Dual-Band WCDMA/HSDPA 850/1900MHz / Quad-Band GSM/GPRS/EDGE 850/900/1800/1900MHz
    E version Dual-Band UMTS/HSDPA 900/2100MHz / Quad-Band GSM/GPRS/EDGE 850/900/1800/1900MHz
    J version Dual-Band UMTS/HSDPA 850(800)/2100MHz / Quad-Band GSM/GPRS/EDGE 850/900/1800/1900MHz
    Ambient Conditions
    Protection Type IP66, Conforms to EN60529
    Operating Temperature -25°C to +70°C
    Storage Temperature -25°C to +85°C
    Telephone Unit Size: 339 *246 *126(mm)
    Gross Weight 7KG
    Pillar Unit Size: 1500 *436 *306(mm)
    Gross Weight 30KG
