Industrial ATEX Certified Service Telephone with Door

IK10 Shock Proof, IP66 Watertight, even when the door is open

Call Us: 555-555-1234

The ATEX Certified, IP66 Weatherproof Industrial Telephone with door is IK10 shock proof and non-corrosive, for use in; Petrochemicals, Oil and Gas Platforms, Power Stations, Tunnels, Military, Dockyards, Ships, Chemical Plants, Universities, Production Factories, Oil Refineries, Mines, Power Plants, Generation Facilities, Paint and Varnish Manufacturing Plants,...

ATEX Series

ATEX Approved Weatherproof Telephone

Versions - Analogue or VoIP SIP

Model: JREX101

  • Robust Non-Corrosive Alloy Die Cast Housing
  • IP66 Weather Protection Rated, IK10 Shock Proof
  • Powered PoE or Analogue Line
  • Vandal Resistant Handset with Steel Armoured Cord
  • Magnetic Hook Receiver (no moving parts)
  • Simple Installation with Tamper Proof Fixings
  • Non-Volatile Memory
  • Full Keypad with Large Buttons for use With Gloves
  • 9 Memory Auto Call, Mute, Flash Recall, Number Recall
  • Remote Programming - DTMF or Web Interface
  • Disabled Assistance - Hearing Induction Loop Included
  • Internal Relays Available On-Demand
  • Customised Labelling and Silk Printing
  • IP66, EX, RoSH, CE & FCC Compliant - 24 Month Warranty

  • IP66 ATEX Certified Weatherproof Industrial Atex Phone with door
    Intrinsically Safe external IP66 ATEX Telephone
    IP66 Weatherproof ATEX Telephone, IK10, red, wall mounted, with door and keypad

    ----- Zone Classifcation -----

      Certificated for use in Hazardous areas of Gas Group IIB/IIA - Zone classification: Zone 1, Zone 2 and Zone 22 - Ex ’d’ protected - Intrinsically safe Ex”ib” certified - Temperature classification:T4

      II 2G Ex e ib [ib] mb IIC T6 Gb

      II 2D Ex ib [ib] tb IIIC T80 °Db

      -40 °C ≤ Ta ≤ +60 °C/+40°C

      Zone 1, 2, 22

    atex certified JRTech explosion proof telphones

    ATEX Classification

    Certificated for use in Hazardous areas of Gas Group IIB/IIA - Zone classification: Zone 1, Zone 2 and Zone 22 - Ex ’d’ protected - Intrinsically safe Ex”ib” certified - Temperature classification:T4

      II 2G Ex e ib [ib] mb IIC T6 Gb

      II 2D Ex ib [ib] tb IIIC T80 °Db

      -40 °C ≤ Ta ≤ +60 °C/+40°C

      Zone 1, 2, 22

    IP66 Weatherproof  Industrial Standard Telephone
    ATEX Series Telephones are designed for use in hazardous and demanding environments, the telephone enclosure provides extra protection from the ingress of dust, dirt and fibres as well as resistance against the harmful and corrosive effects of water spray, rain, sleet or snow. Suitable for temperatures between -40 to +60 deg C. The loud ringer with quality clear audio is adjustable up to 95dB (VoIP / SIP) and 80-85 DB (Analogue). Additional external ATEX horn speaker (110DB@1m) and LED flashing beacons can be specified for use in extreme ambient noise zones. The weatherproof IP66 rating conforms to EN60529. IP66 rating is guaranteed when ther door is open for optimum performance in uncompromising environments. Full duplex, high quality acoustic properties, programmable by DTMF or via web interface (Version Dependent) to ensure optimum locational performance.
    Robust and Vandal Resistant

    Impact protection IK10 rated in accordance to EN50102. Housed within corrosion resistant alloy die cast case, with NPT conduit entries, a unique external telephone compromising off a robust handset, steel armoured cable and anti-tamper fixings. The rugged telephone is ideal for wall or pole installation within harsh, noisy industrial locations. The JRTel range of pillar and posts offer further mounting options.

    Full Keypad

    Large rubber buttons for ease of use whilst wearing gloves. Numbers 0-9 with a 9 memory auto speed-dial (on demand), "LR" button for last number redial, "R" for flash recall and "M" for muting.

    Optional Door Enclosure

    The telephone is available with or without a door. The IP66 rating is maintained, even when the door is open. The door provides extra protection against dirt ingress and alleviates potential for misuse or vandalism.

    Internal Relay's - Controlled by Operators Telephone Keypad

    Option for two internal relays with the VoIP telephone. The analogue version can be customised to include 2 relays upon request. Enter a PIN code via telephone keypad to open door or gate, sound an alarm, switch on a camera or light etc.

    Disable Assistance Fitted Hearing Loop Technology

    Induction Loop Technology is fitted to the telephone handset as standard to assist hard of hearing users.

    Simple to Setup and Maintain

    Programming by way of DTMF for Analogue Networks and powered by Analogue Line. The VoIP SIP version is powered by PoE and programmed via web interface.

    Choice of Colours

    Industrial high-performance epoxy powder coating in RAL colours. Red as standard, however, other colours are available such as; yellow, blue or orange.

    Need a Free Standing or Mounted Option?

    Free-Standing options available with the ATEX Series Telephones with option for pillar or post mounting.

    FC - This mark indicates compliance with FCC Part 15 Subpart B Class B

    CE - This mark indicates compliance with the: Radio and Telecommunications Terminal Equipment Directive 2004/108/EC

    Analogue Version
    Power Supply Standard Analogue Telephone Line
    Supply Voltage 24 VDC to 65 VDC
    Supply Current 20 mA DC to 100 mA DC
    Ringer Volume 80dB(A) at 1m. 110dB(A) at 1m with external horn speaker
    Dialling Method DTMF mode in accordance with ITU-T recommendation Q.23.
    SIP Version
    Power Supply PoE or 12V DC
    Power Consumption Idle:1.5W-Active:1.8W
    SIP Protocol SIP 2.0 (RFC3261)
    Support Codec G.711 A/U, G.722 8000/16000, G.723, G.729
    Communication Type Full Duplex
    Ringer volume 90~95dB(A) at 1m. 110dB(A) at 1m (external horn speaker)
    Explosion Protection:
    Conforms To II 2G Ex e ib [ib] mb IIC T4 Gb III 2D Ex ib [ib] tb IIIC T135 ° -40 °C ≤ Ta ≤ +60 °C/+40°C Zone 1, 2, 22
    Casing Material Die cast aluminium, epoxy powder coated.
    Handset With noise cancelling microphone, for effective communication for noisy areas. Armoured SS cord stands up to rough treatment, option for black curly cord.
    Keypad Weather resistant full Keypad, No.of keys:0-9, *, #, Redial, Mute, Last Number Redial
    Ringing Tone Built-in External Ringer that provides penetrating calling signal (80db - 95A@1meter, version dependant)
    Hook switch Electronic / magnetic with no visible moving parts
    Ambient Conditions
    Lightning / Transients Protection to ITU-T k.21 enhanced levels
    Protection Type IP67, Conforms to EN60529
    Operating Temperature -40°C to +60°C
    M.T.B.F. Calculated to have an M.T.B.F. in excess of 50,000 hours in use
    Unit Size: 204 *334 *126(mm)
    Gross Weight 8KG

    what is atex, undertanding atex ex
